Measuring range 0 - 1000 °C

Sensor Thermopile

Spectral range 8 - 14 µm

Response time t98 ≤ 30 ms

Measurement uncertainty 1 % of temp. reading [°C], min. 2 K

Repeatability 1 K

Temperature coefficient 0.1 K/K (T < 250 °C)

0.04 %/K (T > 250 °C)

Resolution interface 0.1 K

Resolution display 0.1 K < 200 °C

1 K ≥ 200 °C

Optical variants

Lenses Standard-Objektiv PZ 10.01: Fokussierung 0,3 m - ∞

Close-up lens PZ 10.05: focusing 0.15 m - 0.3 m

Electrical parameters

Interface USB

Power supply Rechargeable battery pack

Battery life: approx. 15 hours (based on continuous operation at Ta=23 °C)

Features

Sighting option Through-the-lens-sighting

Display 4-digit LED display red, digit-height 8 mm

Status display 2 x LED external

3 x LED internal

Control elements 3 buttons

General parameters

Ambient temperature 0 - 50 °C

Storage temperature -20 - +60 °C

Permissible humidity 95 % r.H. max. (non-condensing)

Dimension Ø 65 mm x 197 mm (plus lens length)

Housing Aluminum

Protection class IP 40 acc. to DIN 40050

Weight approx. 1.1 kg
